TracWall v2

TracWall

Adaptable Monitor Wall System

Free standing systems for creating custom display stands and multi-screen video monitor walls as part of an optimized control room system. TracWall monitor walls are unique in the industry for its design with specialized cable management and modularity.

Standard TracWall Features

For additional features and further information, please refer to our product guide in the downloads section below.

1
2
3
4
5
6
7
TracWall Features
1

Optional Mounting Area for accessories such as 2RU clock boxes or center channel speakers.

2

Tilting mount or slim bezel push-out mount options.

3

Equipment base cabinets for CPUs or rack mounted equipment.

4

Mounting trac for speakers or other accessories.

5

Power and cable management.

6

End leg with snap-out cover to hide cabling.

7

Height adjustable option available.

Which TracWall Version Fits My Needs?

Customizable base cabinets are available with all TracWalls but needs to be specified at the time of purchase.  They are available in two basic types:

1
2
3
4
5
1

Removable top panels.

2

Cable port to adjacent cabinet if required.

3

Optional CPU pullout shelf.

4

Cable port, typically 2 places.

5

Optional vented rear doors.

TracWall CPU Base Cabinet

TracWall Equipment Base Cabinet

All designs, plans, ideas and specifications indicated in this drawing remain the entire property of TBC Consoles Inc., and may not be used in any manner without prior written consent.

1
2
3
4
5
6
7
Monitor Tilt
1

AM-LMV VESA Pattern

2

AM-LMV Fully Collapsed

3

AM-LMV Fully Expanded

4

AM-LMV Service Position

5

AM-LMV Dimensions

6

AM175 Dimensions

7

AM175 Expansion

AM-LMV/AM-LMVS (left) and AM-175 (right) articulating monitor mounts shown above.

Click a hotspot above for features/dimensions.

Free standing modular systems for creating custom display stands and multi-screen video monitor walls.

V1 Series

Our basic aluminum extrusion grid system is used in basic applications where a larger foot or end leg is not able to fit into the floor plan.  This does not have the same wire-management options as our V2 series but does come with horizontal wire channels.

V2 Series

V2 series is utilizes the same gridwork of structural t-slotted aluminum for monitor wall arrangement.  It is built in order to allow for future modifications and upgrades and can accommodate any monitor size and a variety of tilt/swivel articulating mount options.

Custom Solutions

Custom monitor wall solutions are available when large projects require them.  Typically these solutions involve a combination of millwork and our t-slotted aluminum to convey a built-in look or meet a custom application.

View TracWall Configurations
